Specification
DT-CCDS-A：
Centralized distribution system for ultrapure Acid dialysis concentrate standard type
DT-CCDS-B：
Centralized distribution system for ultrapure sodium bicarbonate dialysis concentrate standard type
DT-CCDS-MINIA：
Centralized distribution system for ultrapure Acid dialysis concentrate Mini type
DT-CCDS-MINIB：
Centralized distribution system for ultrapure sodium bicarbonate dialysis concentrate Mini type
Professional design:
• Free choice of single/Double stream centralized distribution system to meet individual needs.
• The mixture part and distribution part of liqud are placed independently, the demand for the environment of the equipment room is not high.
• The suitable height of the feeding port and the scientific operation angle will bring more convenience for operator.
• The horizontal swirl and vertical Somersault double 3D mixing can accelerate the dissolution rate of dry powder and reduce the preparation time.
• No disinfection blind area of the circulation pipeline and fast flug design, more accurate simulation of conventional supply mode.
• No influence to the internal structure of the hemodialysis machine, different supply modes can be switched at any time.
Extreme function:
■ One button automatic mixing and distribution of fluid,fully automatic cleaning of liquid storage barrel and push of liquid,one button type whole pipeline disinfection.
■ Intelligent reminder for insufficient liquid storage.
■ Setting up residual fluid collection function in each possible waste step to ensure no waste of high purity dialysis concentrate.
■ The lean heating up module and thermal insulation measures ensure dissolution rate and prevent forming of crystallization.
■ Multiple emergency measures to ensure that the constant supply of fluid.
■ The system can be with conductance detection, real-time display of remainder and ozone disinfection.
Super quality and service:
■ SIEMENS brand touch screen and full automatic control core,Schneider electrical components,1/1000 level control module and calibration mode to ensure the precision of the liquid.
■ Adopt medical grade American CPC fast plugs and high polymer heat-resistant U type liquid supply elbow.
Remarks:
Customs should provide drawing of ward planning to our sales after confirming the order for communication of details and construction plans.
|
